Complete unit
- DSG-2 A Series model options - 90kW / 110kW / 132kW / 160kW / 200kW
- Ready for operation
- Fully automatic
- Silenced
- Vibration-damped
- Service-friendly design
- For ambient temperatures up to +45 °C
Airend
- Two-stage, dry compression rotary screw compressor with precision gearing as per AGMA Q13/DIN- 5
- 2nd compression stage uses stainless steel rotors and jacket cooling
- Rotors feature durable coating
- Integrated oil tank with oil tank ventilation
- Fibre-free pulse dampers downstream of both compression stages
Drive motor
- Internationally renowned SIEMENS manufacture
- Premium and Super Premium Efficiency Motor
- Continuous monitoring of motor winding temperature
- Enclosure protection: IP 55
Cooling
- Generously dimensioned compressed air aftercooler combinations comprising stainless steel precooler and aluminium cooler
- Reliable compressor performance up to 45 °C
- Aluminium cooler for gear oil
Electrical components
- Control cabinet to IP 54
- Switching cabinet ventilation
- Automatic star-delta protection combination
- Control transformer
